A Practical Automatic Car Wash Machine for Your Business
Speed S3 is a touchless automatic car wash machine. The vehicle remains stationary while the gantry moves forward and backward, with top and side spray systems and shampoo/foam delivery. It uses an industrial Delta PLC controller and offers three wash programs (Quick, Medium and Long). Designed for car wash sites, fuel stations and new projects, with straightforward operation and maintenance, technical support and spare parts.
Key Features:
Touchless two-arm automatic washing
Top and side spraying
18 water nozzles and 8 foam nozzles
Delta PLC automatic control
Shampoo and foam systems
3 wash programs (Quick, Medium, Long)
Easy maintenance and spare parts availability
Manual service / test mode
24-month warranty against manufacturing defects in electrical and mechanical parts
12 months of free technical support, including remote diagnosis and guidance
Technical Specifications:
Washing Type:Touchless / Two-Arms.
Operation:Stationary vehicle, moving gantry (forward and backward).
Machine Dimensions:L 6.50 m × W 3.20 m × H 3.00 m.
Suggested Installation Space:7 m × 3.5 m × 3 m. Final dimensions are confirmed after a site inspection.
Max. Vehicle Size:Length 5.80 – 5.90 m × Width 2.00 m × Max. height 2.20 m.
Water Consumption:150 – 200 liters per vehicle.
Wash Program Duration:Quick 2 min, Medium 4 min, Long 5 min.
Theoretical Capacity:12 – 30 vehicles per hour depending on the program (Quick 30, Medium 15, Long 12), excluding vehicle entry and exit time.
Control System:Delta PLC.
Drying:Not available.
Optional Upgrades (not included as standard):
C5 anti-corrosion paint
Remote control and monitoring via mobile
7-inch HMI screen
Pressure pump upgrade to 18 – 20 bar
These upgrades are available on request only.
